OpenID Connect

Created on January 26, 2025 | Last updated on January 26, 2025 by
OpenID Connect

What is OpenID Connect?

  • The OpenID Connect (hereafter, OIDC) provides an identity layer on top of OAuth 2.0
  • Designed for user authentication

Tech Stack

The tech stack used for this article includes:

  • RHEL
  • Ubuntu
  • Keycloak
  • Docker
  • Flask
  • HTML/CSS and JS

Sequence diagram

TODO

Keycloak

Add the user in docker group:

sudo usermod -aG docker ${USER}

Start Keycloak

docker run -p 8080:8080 \
-e KC_BOOTSTRAP_ADMIN_USERNAME=admin \
-e KC_BOOTSTRAP_ADMIN_PASSWORD=admin \
quay.io/keycloak/keycloak:26.1.0

Log in to the Admin Console: localhost:8080

Create realm

A realm manages a set of users, credentials, roles, and groups.

Create user

Set password for this user:

WordPress

Create a client

In Keycloak, clients are applications or services.

Click Next

Turn on Client authentication

  • On means confidential access type
  • Off means public access type

Select Standard Flow as Authentication flow. This enables support of Authorization Code Flow for this client.

Click Next

Goto to the Credentials tab, and copy Client Secret for later use.

That's all for Keyclock client setup. Now, let's setup a WordPress website.

Docker compose

Create docker-compose.yaml inside wordpress folder:

services:
  wordpress:
    image: wordpress:latest
    container_name: wpTutorial
    restart: always
    ports:
      - "5001:80"
    environment:
      WORDPRESS_DB_HOST: dbWP:3306
      WORDPRESS_DB_NAME: wpTutorial
      WORDPRESS_DB_USER: root
      WORDPRESS_DB_PASSWORD: s3crets
    depends_on:
      - db

  db:
    image: mysql:5.7
    container_name: dbWP
    restart: always
    environment:
      MYSQL_ROOT_PASSWORD: s3crets
      MYSQL_DATABASE: wpTutorial
    volumes:
      - db_data:/var/lib/mysql

volumes:
  db_data:
    driver: local
  • This Docker compose file defines two servcies i.e., WordPress and MySQL
  • The WordPress website can be browsed from http://192.168.0.123:5001 (replace with your IP)

Now, run docker compose:

docker compose up -d

WordPress setup

Browse http://192.168.0.123:5001, and run the WordPress setup.


Login as admin on http://192.168.0.123:5001/wp-admin/

Note: The objective of this section is to enable Keycloak's OpenID Connect functionality for users within Keycloak.

WordPress OpenID Connect plugin

Install and active the plugin called OpenID Connect Generic Client

Go to http://KEYCLOAK_IP:PORT/realms/YOUR_REALM/.well-known/openid-configuration

Or, go to Keycloak admin page > Real settings > and click on OpenID Endpoint Configuration as shown below:

As this will be important to fill out the OpenID Connect Client settings.

Goto Settings > OpenID Connect Client settings, and fill out inputs as mentioned below:

Key Value
Login Type OpenID Connect button on login form
Client ID wordpress-client
Client Secret Key qFk2y6wqro68QukoKaehGXoEn9bXVJB0
OpenID Scope email profile openid offline_access
Login Endpoint URL http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/auth
Userinfo Endpoint URL http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/userinfo
Token Validation Endpoint URL http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/token
End Session Endpoint URL http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/logout
ACR values leave this empty
Identity Key preferred_username
Disable SSL Verify leave this empty
HTTP Request Timeout 5
Nickname Key preferred_username
Email Formatting {email}
Display Name Formatting leave this empty
Identify with User Name leave this empty
State time limit 180
Enable Refresh Token enabled
Link Existing Users leave this empty
Create user if does not exist enabled
Redirect Back to Origin Page leave this empty
Redirect to the login screen when session is expired enabled
Enforce Privacy leave this empty
Alternate Redirect URI leave this empty
Enable Logging leave this empty
Log Limit 1000

And save changes.

Login with OpenID Connect

Now, browse http://192.168.0.123:5001/wp-admin

Click on Login with OpenID Connect

Sign with Keycloak user testuser and password s3crets

Flask

Create a client

Create a Keycloak client flask-client as mentioned below:

  • Client ID: flask-client
  • Name: Flask project client
  • Client authentication: On
  • Authorization: Off
  • Authentication flow
    • Standard flow: Enabled
    • Direct access grants: Disabled
  • Root URL: http://192.168.0.123:5002
  • Home URL: not required
  • Valid redirect URIs: http://192.168.0.123:5002/*
  • Valid post logout redirect URIs: not required
  • Web origins: *

Click Save

Now, make a note of client secrets for later use.

Flask

Create flask-project

mkdir flask-project
cd flask-project

docker-compose.yaml

Create docker-compose.yaml

touch docker-compose.yaml

Paste the following yaml:

services:
  web:
    build: .
    ports:
      - "5002:5000"
    develop:
      watch:
        - action: sync
          path: .
          target: /code

Dockerfile

Create Dockerfile

touch Dockerfile

Paste:

WORKDIR /code
ENV FLASK_APP=app.py
ENV FLASK_RUN_HOST=0.0.0.0
RUN apk add --no-cache gcc musl-dev linux-headers
COPY requirements.txt requirements.txt
RUN pip install -r requirements.txt
EXPOSE 5000
COPY . .
CMD ["flask", "run", "--debug"]

requirements.txt

Create requirements.txt

flask
requests

index.html

Create index.html

mkdir templates
touch index.html
<html>
<body>
    <p>
        Welcome, {{ user_info_obj.preferred_username }}
    </p>
    <hr>
    <p>{{ user_info_obj.email }}</p>
    <p>{{ user_info_obj.email_verified }}</p>
    <p>{{ user_info_obj.upn }}</p>
    <p>
        <a href="/logout">Logout</a>
    </p>
</body>
</html>

app.py

Create app.py inside flask-project

pwd

/home/tux/opt/tutorial/flask-project
touch app.py

Paste the following code:

import os
import requests
from flask import Flask, redirect, request, session, url_for, render_template

app = Flask(__name__)
app.secret_key = os.urandom(24)

# Keycloak settings
KEYCLOAK_SERVER = 'http://192.168.0.123:8080'
REALM_NAME = 'Tutorial'
CLIENT_ID = 'flask-client'
CLIENT_SECRET = 'yakhrUZBx8aIzDPH2FqiRBE286EqYEzm'
REDIRECT_URI = 'http://192.168.0.123:5002/callback'

# Keycloak OIDC endpoints
AUTHORIZATION_URL = f"{KEYCLOAK_SERVER}/realms/{REALM_NAME}/protocol/openid-connect/auth"
TOKEN_URL = f"{KEYCLOAK_SERVER}/realms/{REALM_NAME}/protocol/openid-connect/token"
USERINFO_URL = f"{KEYCLOAK_SERVER}/realms/{REALM_NAME}/protocol/openid-connect/userinfo"

@app.route('/')
def home():
    '''
    '''
    if 'user_info' in session:
        user_info_obj = session['user_info']
        return render_template('index.html', user_info_obj=user_info_obj)

    return redirect(url_for('login'))

@app.route('/login')
def login():
    '''
    Redirect to Keycloak login page
    '''
    auth_url = f"{AUTHORIZATION_URL}?client_id={CLIENT_ID}&response_type=code&scope=openid&redirect_uri={REDIRECT_URI}"
    return redirect(auth_url)

@app.route('/callback')
def callback():
    '''
    '''
    # Get authorization code from Keycloak
    code = request.args.get('code')

    # Request access token using the code
    token_data = {
        'grant_type': 'authorization_code',
        'code': code,
        'redirect_uri': REDIRECT_URI,
        'client_id': CLIENT_ID,
        'client_secret': CLIENT_SECRET
    }

    response = requests.post(TOKEN_URL, data=token_data)
    response_data = response.json()

    if 'access_token' not in response_data:
        return "Error: No access token found.", 400

    access_token = response_data['access_token']

    # Fetch user info from Keycloak
    user_info_response = requests.get(
        USERINFO_URL,
        headers={'Authorization': f'Bearer {access_token}'}
    )

    if user_info_response.status_code != 200:
        return "Error: Could not retrieve user info.", 400
    user_info = user_info_response.json()

    # Store user info in session
    session['user_info'] = user_info

    return redirect(url_for('home'))

@app.route('/logout')
def logout():
    session.pop('user_info', None)
    logout_url = f"{KEYCLOAK_SERVER}/realms/{REALM_NAME}/protocol/openid-connect/logout"
    return redirect(logout_url)

The flask-project structure should look like this:

flask-project/
├── Dockerfile
├── app.py
├── docker-compose.yaml
├── requirements.txt
└── templates
    └── index.html

Now, let's run the docker

docker compose up

Output:

Browse http://192.168.0.123:5002/

As soon as you enter http://192.168.0.123:5002/, the browser address gets redirect to http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/auth?client_id=flask-client&response_type=code&scope=openid&redirect_uri=http://192.168.0.123:5002/callback with Keycloak login page.

Let's decode this:

URL / URL fragments Description
http://192.168.0.123:8080/realms/Tutorial/protocol/openid-connect/auth AUTHORIZATION_URL
?client_id=flask-client Client that we've created on the Keycloak
&response_type=code Response type is code
&scope=openid Scope is openid
&redirect_uri=http://192.168.0.123:5002/callback This is redirect URI

Now, Login with Keycloak user's credentials

With the correct credentials, you'll be granted access to the flask-client application

And logout shall end the session
